Quickstart Guide

To start a demo model training, you need to prepare three things: installation, dataset preparation, and model training configuration. In this guide, we will first cover the steps for dataset preparation and then briefly describe the model training configuration.

Installation

Please refer to the installation guide for instructions on how to install the necessary dependencies.

Data Preparation

Pre-training

Using Hugging Face format dataset

If you use a Hugging Face dataset, you need to first download the dataset and the required tokenizer to your local machine.

Using the roneneldan/TinyStories dataset as an example, the data preparation phase requires downloading the dataset to your local system with the following command:

huggingface-cli download --repo-type dataset --resume-download "roneneldan/TinyStories" --local-dir "/mnt/petrelfs/hf-TinyStories"

In this case, “/mnt/petrelfs/hf-TinyStories” is the local path where the dataset needs to be saved.

Next, download the tokenizer to your local system. For instance, if you are using the internlm2 tokenizer, download the files special_tokens_map.json, tokenizer.model, tokenizer_config.json, tokenization_internlm2.py, and tokenization_internlm2_fast.py from the repository at “https://huggingface.co/internlm/internlm2-7b/tree/main” to a local directory, such as “/mnt/petrelfs/hf-internlm2-tokenizer”.

Make the following changes to the configuration file:

TRAIN_FOLDER = "/mnt/petrelfs/hf-TinyStories"
data = dict(
    type="streaming",
    tokenizer_path="/mnt/petrelfs/hf-internlm2-tokenizer",
)

The type is set to “tokenized” by default, but here it needs to be changed to the “streaming” type. Also, you need to specify the tokenizer_path. If you are using the dataset that has been tokenized as described below, you do not need to set this field. The TRAIN_FOLDER specifies the path to the local dataset.

Use the dataset after tokenization

The dataset for the InternEvo training task includes a series of bin and meta files. A tokenizer is used to generate the training dataset from the original text files. The tokenizer model is imported by specifying the model parameter path in tools/tokenizer.py. Currently, tokenizer_internlm.model is provided to generate tokens. If you want to use a different model, you can directly modify the model parameter path in tokenizer.py.

You can run the following command to generate bin and meta files corresponding to the original data. The parameter text_input_path represents the path of the original text data, currently supporting txt, json, and jsonl formats, while bin_output_path represents the save path of the generated bin files.

$ python tools/tokenizer.py --text_input_path your_input_text_path --bin_output_path your_output_bin_path

Here is an example of data processing:

Given a file raw_data.txt containing the raw dataset, the raw dataset is shown below:

感恩生活中的每一个细节，才能真正体会到幸福的滋味。
梦想是人生的动力源泉，努力追逐，才能实现自己的目标。
学会宽容和理解，才能建立真正和谐的人际关系。

You can generate the bin and meta files by running the following command:

$ python tools/tokenizer.py --text_input_path raw_data.txt --bin_output_path cn/output.bin

It should be noted that the generated bin files need to be saved in one of the following directories: cn, en, code, ja, ar, or kaoshi, depending on the type of dataset.

Here, cn represents the Chinese dataset, en represents the English dataset, code represents the code dataset, ja represents the Japanese dataset, ar represents the Arabic dataset, and kaoshi represents the exam dataset.

The format of the generated bin files is as follows:

{"tokens": [73075, 75302, 69522, 69022, 98899, 67713, 68015, 81269, 74637, 75445, 99157]}
{"tokens": [69469, 60355, 73026, 68524, 60846, 61844, 98899, 67775, 79241, 98899, 67713, 67800, 67453, 67838, 99157]}
{"tokens": [68057, 79017, 60378, 68014, 98899, 67713, 67990, 68015, 70381, 67428, 61003, 67622, 99157]}

Each line in the bin file corresponds to each sentence in the original dataset, representing the tokens of each sentence (referred to as sequence below).

The format of the generated meta file is as follows:

(0, 11), (90, 15), (208, 13)

Each tuple in the meta file represents the meta information of each sequence, where the first element in the tuple indicates the starting index of each sequence among all sequences, and the second element indicates the number of tokens for each sequence.

For example, the first sequence starts at index 0 and has 16 tokens. The second sequence starts at index 110 and has 24 tokens.

The bin and meta file formats for json and jsonl type files are the same as for txt, so we won’t go over them here.

Fine-tuning

The data format for fine-tuning tasks is the same as for pre-training tasks, which consists of a series of bin and meta files. Let’s take the Alpaca dataset as an example to explain the data preparation process for fine-tuning.

1. Download the Alpaca dataset.

2. Tokenize the Alpaca dataset using the following command:

python tools/alpaca_tokenizer.py /path/to/alpaca_dataset /path/to/output_dataset /path/to/tokenizer --split_ratio 0.1

It is recommended that users refer to alpaca_tokenizer.py to write new scripts to tokenize their own datasets.

In fine-tuning tasks, Hugging Face formatted datasets can also be used, consistent with the preparation process in pre-training.

Training Configuration

Taking the configuration file configs/7B_sft.py for the 7B demo as an example,

JOB_NAME = "7b_train"
DO_ALERT = False

SEQ_LEN = 2048
HIDDEN_SIZE = 4096
NUM_ATTENTION_HEAD = 32
MLP_RATIO = 8 / 3
NUM_LAYER = 32
VOCAB_SIZE = 103168

MODEL_ONLY_FOLDER = "local:llm_ckpts/xxxx"
# Ckpt folder format:
# fs: 'local:/mnt/nfs/XXX'
SAVE_CKPT_FOLDER = "local:llm_ckpts"

# boto3 Ckpt folder format:
# import os
# BOTO3_IP = os.environ["BOTO3_IP"] # boto3 bucket endpoint
# SAVE_CKPT_FOLDER = f"boto3:s3://model_weights.{BOTO3_IP}/internlm"
CHECKPOINT_EVERY = 50
ckpt = dict(
    enable_save_ckpt=False,  # enable ckpt save.
    save_ckpt_folder=SAVE_CKPT_FOLDER,  # Path to save training ckpt.
    # 'load_ckpt_info' setting guide:
    # 1. the 'path' indicate ckpt path,
    # 2. the 'content‘ means what states will be loaded, support: "model", "sampler", "optimizer", "scheduler", "all"
    # 3. the ’ckpt_type‘ means the type of checkpoint to be loaded, support: "internevo", "hf", or other custom-defined
    # load function such as "llama"
    load_ckpt_info=dict(path=MODEL_ONLY_FOLDER, content=("model",), ckpt_type="internevo"),
    # 'auto_resume' is designed to automatically load the latest checkpoint from 'save_ckpt_folder' when encountering
    # training interruptions/hangs caused by hardware failures, using a scheduling system (such as k8s/slurm)
    # with an automatic restart mechanism upon training reboot.
    # Please be aware that if `auto_resume` is not set (its default value is True), it will not load the checkpoint
    # path specified in `load_ckpt_info` by default.
    # If you want to initialize your model weights from another model, you must set `auto_resume` to False.
    # If you want to train from scratch, please set `auto_resume` to False and 'load_ckpt_info' to None.
    auto_resume=True,
    checkpoint_every=CHECKPOINT_EVERY,
    async_upload=True,  # async ckpt upload. (only work for boto3 ckpt)
    async_upload_tmp_folder="/dev/shm/internlm_tmp_ckpt/",  # path for temporarily files during asynchronous upload.
    oss_snapshot_freq=int(CHECKPOINT_EVERY / 2),  # snapshot ckpt save frequency.
)

TRAIN_FOLDER = None  # "/path/to/dataset"
VALID_FOLDER = None  # "/path/to/dataset"
data = dict(
    seq_len=SEQ_LEN,
    # micro_num means the number of micro_batch contained in one gradient update
    micro_num=4,
    # packed_length = micro_bsz * SEQ_LEN
    micro_bsz=2,
    # defaults to the value of micro_num
    valid_micro_num=4,
    # defaults to 0, means disable evaluate
    valid_every=50,
    pack_sample_into_one=False,
    total_steps=50000,
    skip_batches="",
    # rampup_batch_size (str): A string with three space-separated integers representing the
    #       starting batch size, the increment, and the number of steps between
    #       each increment. For example, "192 24 8" means that the batch size (micro_num)
    #       starts at 192 and increases by 24 every 8 steps. Defaults to None.
    #       (IMPORTANT): The interval step size is 'micro_bsz'.
    rampup_batch_size="",
    # Datasets with less than 50 rows will be discarded
    min_length=50,
    train_folder=TRAIN_FOLDER,
    valid_folder=VALID_FOLDER,
    empty_cache_and_diag_interval=200,
    diag_outlier_ratio=1.1,
    # whether use shared memory to load meta files
    use_shm=False,
    # when use shm, the default shm_path is "/dev/shm/metacache"
    # shm_path="/dev/shm/metacache"
)

grad_scaler = dict(
    fp16=dict(
        # the initial loss scale, defaults to 2**16
        initial_scale=2**16,
        # the minimum loss scale, defaults to None
        min_scale=1,
        # the number of steps to increase loss scale when no overflow occurs
        growth_interval=1000,
    ),
    # the multiplication factor for increasing loss scale, defaults to 2
    growth_factor=2,
    # the multiplication factor for decreasing loss scale, defaults to 0.5
    backoff_factor=0.5,
    # the maximum loss scale, defaults to None
    max_scale=2**24,
    # the number of overflows before decreasing loss scale, defaults to 2
    hysteresis=2,
)

hybrid_zero_optimizer = dict(
    # Enable low_level_optimzer overlap_communication
    overlap_sync_grad=True,
    overlap_sync_param=False,
    # bucket size for nccl communication params
    reduce_bucket_size=512 * 1024 * 1024,
    # grad clipping
    clip_grad_norm=1.0,
    # whether use new optm
    use_split_tensor_optim=False,
    # when use split tensor optm
    # Perform all gather with a set of parameters of all_gather_size
    all_gather_size=512 * 1024 * 1024,
)

loss = dict(
    label_smoothing=0,
)

adam = dict(
    lr=1e-4,
    adam_beta1=0.9,
    adam_beta2=0.95,
    adam_beta2_c=0,
    adam_eps=1e-8,
    weight_decay=0.01,
)

lr_scheduler = dict(
    total_steps=data["total_steps"],
    init_steps=0,  # optimizer_warmup_step
    warmup_ratio=0.01,
    eta_min=1e-5,
    last_epoch=-1,
)

beta2_scheduler = dict(
    init_beta2=adam["adam_beta2"],
    c=adam["adam_beta2_c"],
    cur_iter=-1,
)

use_fp32_norm = False
model = dict(
    checkpoint=False,  # The proportion of layers for activation aheckpointing, the optional value are True/False/[0-1]
    num_attention_heads=NUM_ATTENTION_HEAD,
    embed_split_hidden=True,
    vocab_size=VOCAB_SIZE,
    embed_grad_scale=1,
    parallel_output=True,
    hidden_size=HIDDEN_SIZE,
    num_layers=NUM_LAYER,
    mlp_ratio=MLP_RATIO,
    apply_post_layer_norm=False,
    dtype="torch.bfloat16",  # Support: "torch.float16", "torch.half", "torch.bfloat16", "torch.float32", "torch.tf32"
    norm_type="rmsnorm",
    layer_norm_epsilon=1e-5,
    use_flash_attn=True,
    # Whether the odd and even columns of the query and key in the model are normally interleaved.
    # If it's True, the model's odd and even columns are normally ordered; if it's False,
    # it means that the model has prematurely concatenated all odd columns and even columns in front
    # and back, in order to improve the RoPE's computational efficiency.
    # Example:
    # qk_interleaved = True: q[-1] = [q1,q2,q3,q4,q5,q6,...], k[-1] = [k1,k2,k3,k4,k5,k6,...]
    # qk_interleaved = False: q[-1] = [q1,q3,q5,...,q2,q4,q6,...], k[-1] = [k1,k3,k5,...,k2,k4,k6,...]
    qk_interleaved=False,
    num_chunks=1,  # if num_chunks > 1, interleaved pipeline scheduler is used.
)
"""
zero1 parallel (dict):
    1. size: int
        * if size <= 0, the size of the zero process group is equal to the size of the dp process group,
            so parameters will be divided within the range of dp.
        * if size == 1, zero is not used, and all dp groups retain the full amount of model parameters.
        * if size > 1 and size <= dp world size, the world size of zero is a subset of dp world size.
        For smaller models, it is usually a better choice to split the parameters within nodes with a setting <= 8.
tensor parallel (dict):
    1. size: int, the size of tensor parallel.
    2. mode: str, the tensor parallel mode, should be in ['mtp', 'msp', 'fsp', 'isp'],
        defaults to 'mtp', means the pure megatron tensor parallel without sequence parallel.
        msp: megatron tensor parallel with sequence parallel, sequence parallel size = tensor parallel size.
        fsp: tensor parallel by flash-attn with sequence parallel, sequence parallel size = tensor parallel size.
        isp: customed intern sequence parallel without tensor parallel, can be used with weight parallel.
pipeline parallel (dict):
    1. size: int, the size of pipeline parallel.
    2. interleaved_overlap: bool, enable/disable communication overlap when using interleaved pipeline scheduler,
        defaults to False.
weight parallel (dict):
    1. size: int, the size of weight parallel.
    2. overlap: bool, enable/disable all_gather/reduce_scatter communication overlap, defaults to False.
"""
parallel = dict(
    zero1=dict(size=-1),
    tensor=dict(size=1, mode="mtp"),
    pipeline=dict(size=1, interleaved_overlap=True),
    weight=dict(size=1, overlap=True),
)

cudnn_deterministic = False
cudnn_benchmark = False

monitor = dict(
    # feishu alert configs
    alert=dict(
        enable_feishu_alert=DO_ALERT,
        feishu_alert_address=None,  # feishu webhook to send alert message
        light_monitor_address=None,  # light_monitor address to send heartbeat
        alert_file_path=f"llm_alter/{JOB_NAME}_alert.log",
    ),
    tensorboard=dict(
        queue_max_length=10,
    ),
)

let’s discuss the data, model, parallel and monitoring configurations required to start a model training.

Data Configuration

Here are the key parameters and their explanations for data configuration:

TRAIN_FOLDER = "/path/to/dataset"
SEQ_LEN = 2048
data = dict(
    seq_len=SEQ_LEN,  # 数据样本长度，默认值为 2048
    micro_num=1,  # micro_num 是指在一次模型参数更新中会处理的 micro_batch 的数目，默认值为 1
    micro_bsz=1,  # packed_length = micro_bsz * SEQ_LEN，为一次处理的 micro_batch 的数据大小，默认值为 1
    total_steps=50000,  # 总的所需执行的 step 的数目，默认值为 50000
    min_length=50,  # 若数据集文件中，数据行数少于50，将会被废弃
    train_folder=TRAIN_FOLDER,  # 数据集文件路径，默认值为 None；若 train_folder 为空，则以自动生成的随机数据集进行训练测试
    pack_sample_into_one=False, # 数据整理的逻辑，决定是按照 seq_len 维度或者是 sequence 的真实长度来进行attention计算
)

Currently, it supports passing the dataset file path train_folder, and the file format is required to be as follows:

- folder
    - code
        train_000.bin
        train_000.bin.meta

For detailed information about the dataset, please refer to the “Data Preparation” section.

Additionally, it supports processing of datasets in the Hugging Face format.

Set the train_folder to the local path of the dataset downloaded from Hugging Face, for example: “/mnt/petrelfs/hf-TinyStories”.

In the data section, you need to add new fields for type and tokenizer_path to indicate that the dataset is in Hugging Face format and to specify the path of the tokenizer, for example:

TRAIN_FOLDER = "/mnt/petrelfs/hf-TinyStories"
SEQ_LEN = 2048
data = dict(
    type="streaming",
    tokenizer_path="/mnt/petrelfs/hf-internlm2-tokenizer",
    seq_len=SEQ_LEN,  # 数据样本长度，默认值为 2048
    micro_num=1,  # micro_num 是指在一次模型参数更新中会处理的 micro_batch 的数目，默认值为 1
    micro_bsz=1,  # packed_length = micro_bsz * SEQ_LEN，为一次处理的 micro_batch 的数据大小，默认值为 1
    total_steps=50000,  # 总的所需执行的 step 的数目，默认值为 50000
    min_length=50,  # 若数据集文件中，数据行数少于50，将会被废弃
    train_folder=TRAIN_FOLDER,  # 数据集文件路径，默认值为 None；若 train_folder 为空，则以自动生成的随机数据集
进行训练测试
    pack_sample_into_one=False, # 数据整理的逻辑，决定是按照 seq_len 维度或者是 sequence 的真实长度来进行attention计算
)

Model Configuration

If you want to load a model checkpoint when starting the training, you can configure it as follows:

SAVE_CKPT_FOLDER = "local:/path/to/save/ckpt"
# MODEL_ONLY_FOLDER = "internlm/internlm-7b"
MODEL_ONLY_FOLDER = "local:/path/to/load/resume/ckpt"
ckpt = dict(
    enable_save_ckpt=True,  # 是否开启保存 checkpoint 功能
    save_ckpt_folder=SAVE_CKPT_FOLDER,  # 存储模型和优化器 checkpoint 的路径
    checkpoint_every=float("inf"),  # 每多少个 step 存储一次 checkpoint，默认值为 inf
    # 断点续训时，加载模型和优化器等权重的路径，将从指定的 step 恢复训练
    # content 表示哪些状态会被加载，支持： "model", "sampler", "optimizer", "scheduler", "all"
    # ckpt_type 表示加载的模型类型，目前支持: "internevo", "llama", "hf"
    load_ckpt_info=dict(path=MODEL_ONLY_FOLDER, content=("model",), ckpt_type="internevo"),
    # 'auto_resume' 旨在在遇到由硬件故障引起的训练中断/挂起时，自动从 'save_ckpt_folder' 加载最新的检查点，
    # 使用调度系统（例如 k8s/slurm）在训练重启时自动重启机制。
    # 请注意，如果未设置 auto_resume（其默认值为 True），它将不会默认加载 load_ckpt_info 中指定的检查点路径。
    # 如果你想从另一个模型初始化你的模型权重，必须将 auto_resume 设置为 False。
    # 如果你想从头开始训练，请将 auto_resume 设置为 False 并将 'load_ckpt_info' 设置为 None。
    auto_resume=False,
    async_upload=True,  # 异步检查点上传。（仅适用于 boto3 检查点）
    async_upload_tmp_folder="/dev/shm/internlm_tmp_ckpt/",  # 异步上传期间临时文件的路径。
    oss_snapshot_freq=int(CHECKPOINT_EVERY / 2),  # 快照检查点保存频率。
)

Note:

• If the path starts with local:, it means the file is stored in the local file system. If it starts with boto3:, it means the file is stored in the remote OSS.

The configuration for the model is as follows:

model_type = "INTERNLM"  # 模型类型，默认值为 "INTERNLM"，对应模型结构初始化接口函数
NUM_ATTENTION_HEAD = 32
VOCAB_SIZE = 103168
HIDDEN_SIZE = 4096
NUM_LAYER = 32
MLP_RATIO = 8 / 3
model = dict(
    checkpoint=False,   # 进行重计算的模型层数比例，可选值为 True/False/[0-1]
    num_attention_heads=NUM_ATTENTION_HEAD,
    embed_split_hidden=True,
    vocab_size=VOCAB_SIZE,
    embed_grad_scale=1,
    parallel_output=True,
    hidden_size=HIDDEN_SIZE,
    num_layers=NUM_LAYER,
    mlp_ratio=MLP_RATIO,
    apply_post_layer_norm=False,
    dtype="torch.bfloat16",
    norm_type="rmsnorm",
    layer_norm_epsilon=1e-5,
)

Note: Users can customize the model type name and model structure, and configure the corresponding model parameters. The model initialization function interface can be registered through the MODEL_INITIALIZER object in utils/registry.py. When initializing the model in the training main function train.py, the specified model initialization interface function can be obtained through the model_type configuration.

If you want to start training based on InternLM 7B, you can refer to OpenXLab ModelZoo to download weights.

Parallel Configuration

Training parallel configuration example:

parallel = dict(
    zero1=dict(size=-1),
    tensor=dict(size=1, mode="mtp"),
    pipeline=dict(size=1, interleaved_overlap=True),
    weight=dict(size=1, overlap=True),
)

• zero1 (dict):

  1. size: int

  • When zero1 <= 0 , the size of the zero1 process group is equal to the size of the data parallel process group, so the optimizer state parameters will be split within the data parallel range.

  • When zero1 == 1, zero1 is not used, and all data parallel groups retain the complete optimizer state parameters.

  • When zero1 > 1 and zero1 <= data_parallel_world_size, the zero1 process group is a subset of the data parallel process group.

• tensor (dict):

  1. size: int, size of tensor parallem

  2. mode: string, tensor parallel mode, should be one of [‘mtp’, ‘msp’, ‘fsp’, ‘isp’]

  • Default is ‘mtp’, which means there is no sequence parallelism, just pure tensor parallelism for Megatron.

  • msp: Megatron Tensor Parallelism with Sequence Parallelism, where the size of sequence parallelism is equal to the size of tensor parallelism.

  • fsp: Tensor Parallelism with Sequence Parallelism facilitated by flash-attn, where the size of sequence parallelism is equal to the size of tensor parallelism.

  • isp: Custom internal sequence parallelism, without tensor parallelism, which can be used in conjunction with weight parallelism.

• pipeline: pipeline parallel strategy

  1. size: int, size of pipeline parallel

  2. interleaved_overlap: A boolean value that enables or disables communication overlapping when using an interleaved pipeline scheduler, with the default being False.

• weight (dict):

  1. size: int, size of weight parallel

  2. overlap: bool, enable/disable all_gather/reduce_scatter communication overlap, default is False

Note: Data parallel size = Total number of GPUs / Pipeline parallel size / Tensor parallel size

Start Training

After completing the data preparation and relevant training configurations mentioned above, you can start the demo training. The following examples demonstrate how to start the training in both slurm and torch environments.

If you want to start distributed training on slurm with 16 GPUs across multiple nodes, use the following command:

$ srun -p internllm -N 2 -n 16 --ntasks-per-node=8 --gpus-per-task=1 python train.py --config ./configs/7B_sft.py

If you want to start distributed training on torch with 8 GPUs on a single node, use the following command:

$ torchrun --nnodes=1 --nproc_per_node=8 train.py --config ./configs/7B_sft.py --launcher "torch"

The content of train.py, please refer to: training script

Training Results

Taking the configuration of the demo training on a single machine with 8 GPUs on slurm as an example, the training result log is shown below:

2023-07-07 12:26:58,293	INFO launch.py:228 in launch -- Distributed environment is initialized, data parallel size: 8, pipeline parallel size: 1, tensor parallel size: 1
2023-07-07 12:26:58,293	INFO parallel_context.py:535 in set_seed -- initialized seed on rank 2, numpy: 1024, python random: 1024, ParallelMode.DATA: 1024, ParallelMode.TENSOR: 1024,the default parallel seed is ParallelMode.DATA.
2023-07-07 12:26:58,295	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=0===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=5===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=1===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=6===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=7===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=2===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=4===========
2023-07-07 12:26:58,296	INFO train.py:378 in main -- ===========New Run Jul07_12-26-58 on host:SH-IDC1-10-140-0-135,tp:0,pp=0,dp=3===========
2023-07-07 12:28:27,826	INFO hybrid_zero_optim.py:295 in _partition_param_list -- Number of elements on ranks: [907415552, 907411456, 910163968, 910163968, 921698304, 921698304, 921698304, 921698304], rank:0
2023-07-07 12:28:57,802	INFO train.py:323 in record_current_batch_training_metrics -- tflops=63.27010355651958,step=0,loss=11.634403228759766,tgs (tokens/gpu/second)=1424.64,lr=4.0000000000000003e-07,loss_scale=65536.0,grad_norm=63.672620777841004,micro_num=4,num_consumed_tokens=131072,inf_nan_skip_batches=0,num_samples_in_batch=19,largest_length=2048,largest_batch=5,smallest_batch=4,adam_beta2=0.95,fwd_bwd_time=6.48
2023-07-07 12:29:01,636	INFO train.py:323 in record_current_batch_training_metrics -- tflops=189.83371103277346,step=1,loss=11.613704681396484,tgs (tokens/gpu/second)=4274.45,lr=6.000000000000001e-07,loss_scale=65536.0,grad_norm=65.150786641452,micro_num=4,num_consumed_tokens=262144,inf_nan_skip_batches=0,num_samples_in_batch=16,largest_length=2048,largest_batch=5,smallest_batch=3,adam_beta2=0.95,fwd_bwd_time=3.67
2023-07-07 12:29:05,451	INFO train.py:323 in record_current_batch_training_metrics -- tflops=190.99928472960033,step=2,loss=11.490386962890625,tgs (tokens/gpu/second)=4300.69,lr=8.000000000000001e-07,loss_scale=65536.0,grad_norm=61.57798028719357,micro_num=4,num_consumed_tokens=393216,inf_nan_skip_batches=0,num_samples_in_batch=14,largest_length=2048,largest_batch=4,smallest_batch=3,adam_beta2=0.95,fwd_bwd_time=3.66
2023-07-07 12:29:09,307	INFO train.py:323 in record_current_batch_training_metrics -- tflops=188.8613541410694,step=3,loss=11.099515914916992,tgs (tokens/gpu/second)=4252.55,lr=1.0000000000000002e-06,loss_scale=65536.0,grad_norm=63.5478796484391,micro_num=4,num_consumed_tokens=524288,inf_nan_skip_batches=0,num_samples_in_batch=16,largest_length=2048,largest_batch=5,smallest_batch=3,adam_beta2=0.95,fwd_bwd_time=3.7
2023-07-07 12:29:13,147	INFO train.py:323 in record_current_batch_training_metrics -- tflops=189.65918563194305,step=4,loss=10.149517059326172,tgs (tokens/gpu/second)=4270.52,lr=1.2000000000000002e-06,loss_scale=65536.0,grad_norm=51.582841631508145,micro_num=4,num_consumed_tokens=655360,inf_nan_skip_batches=0,num_samples_in_batch=19,largest_length=2048,largest_batch=6,smallest_batch=3,adam_beta2=0.95,fwd_bwd_time=3.68
2023-07-07 12:29:16,994	INFO train.py:323 in record_current_batch_training_metrics -- tflops=189.3109313713174,step=5,loss=9.822169303894043,tgs (tokens/gpu/second)=4262.67,lr=1.4000000000000001e-06,loss_scale=65536.0,grad_norm=47.10386835560855,micro_num=4,num_consumed_tokens=786432,inf_nan_skip_batches=0,num_samples_in_batch=17,largest_length=2048,largest_batch=6,smallest_batch=3,adam_beta2=0.95,fwd_bwd_time=3.69

Load the training checkpoint and generate.

If you want to start distributed training on slurm with 16 GPUs across multiple nodes, use the following command:

$ srun -p internllm -N 2 -n 16 --ntasks-per-node=8 --gpus-per-task=1 python generate.py --config ./configs/7B_sft.py

Add generation configuration to the configuration file.

generation = dict(
    ckpt_folder="/path/to/saved/ckpt",
    output_folder="/path/to/save/generation",
    batch_size=1,
    eos_id=[2, 0],
    bos_id=1,
    max_length=100,
    do_sample=True,
    temperature=1.0,
    top_k=50,
    top_p=1.0,
    repetition_penalty=1,
    length_penalty=1.0,
)

Long Text Generation

In the inference phase, we can use Dynamic NTK RoPE instead of the original RoPE, allowing the model to handle long-text input and output, achieving extrapolation effects up to 16K. Currently, InternLM supports the use of Dynamic NTK RoPE in models formatted in both Hugging Face format and InternLM’s native format.

1. For models in Hugging Face format, Dynamic NTK RoPE is currently enabled by default. If users wish to disable this behavior, they can modify rotary.type in the config.json file to origin.

2. For models in InternLM’s native format, during inference, you can enable this behavior by adding use_dynamic_ntk_rope=True to the configuration dictionary when initializing the model.

Users can visually compare and observe how Dynamic NTK RoPE takes effect directly through the web_demo. For example, in the file Long Text Example, there is a text with token length exceeding 2200. Without using Dynamic NTK, the model is unable to answer questions related to this text. However, after applying Dynamic NTK RoPE, the response from the InternLM Chat 7B v1.1 model is as follows:

Regarding the principle of Dyanmic NTK, please refer to

1. dynamically_scaled_rope_further_increases

2. https://kexue.fm/archives/9675
